Architecture

The architecture of the infDB-basedata-ways tool is based on the InfDB Dev Container template as described in the Tool Template. The tool is implemented in Python and utilizes the pyinfdb package for interaction with InfDB. The database operations are executed using SQL queries.

Remark

The architecture follows the InfDB Dev Container template. For detailed structure and dependencies, see the Tool Template section.

Overview

The infDB-basedata-ways tool transforms raw ways-related input data into structured road network tables for downstream tools and analyses. The processing is executed through Python-based orchestration and SQL-based transformation steps in InfDB.

Input Tables

The tool reads its source data from existing input tables:

• opendata.basemap_verkehrslinie: Stores the raw way geometries and related source attributes used as the basis for road network generation.
• basedata.buildings: Stores the building geometries and attributes for buildings that are assigned and connected to suitable ways during processing.

Intermediate Tables

During processing, the tool creates and updates temporary or intermediate tables used in the transformation workflow:

• ways_tem: Temporary working table used to process and segment ways for the generation of basedata.ways_per_junction.
• ways_tem_connection: Temporary working table used to process ways for the generation of basedata.ways_per_connection. In this table, ways are additionally split at building-to-way connection points.
• connection_lines_tem: Temporary table used to store the generated building-to-way connection lines during processing.

Output Tables

The tool writes the processed results into global output tables:

• basedata.ways_per_junction: Stores the final way network designed for tools such as the linear heat density tool which requires that the ways are segmented at way junctions but not additionally at building-to-way connection points.
• basedata.nodes_per_junction: Stores the nodes of the way network contained in basedata.ways_per_junction.
• basedata.connection_lines: Stores the generated connection lines between buildings and their assigned ways.
• basedata.ways_per_connection: Stores the final way network designed for tools such as the pylovo tool which requires that the ways are additionally segmented at building-to-way connection intersections.
• basedata.nodes_per_connection: Stores the nodes of the way network contained in basedata.ways_per_connection. These nodes include the buildings, the street-to-street intersections and street-to-connection_line connection points.

Functions

The main logic of the tool is implemented through SQL scripts and database functions. These components support assignment updates, segmentation, splitting operations, and connection generation.

insert_way_segment

Inserts a generated way segment into the corresponding temporary table.

split_way_at_connection_points

Splits a way geometry into multiple segments at connection points.

generate_building_way_connection_candidates

Generates temporary connection candidates between buildings and assigned ways.

update_assigned_way_id_after_merge

Updates buildings.assigned_way_id after way-merging operations.

update_assigned_way_id

Updates buildings.assigned_way_id based on a mapping table or nearest suitable way.

Processing Steps

The SQL-based processing is organized into multiple sequential scripts. These scripts cover initialization, filtering, assignment, merging, segmentation, connection generation, and final insertion into output tables.

1. create_temp_table.sql

Creates the temporary working tables ways_tem and connection_lines_tem from the input ways data restricted to the selected AGS. It keeps one valid LINESTRING per source feature, adds additional columns needed in later processing steps, and creates indexes for efficient spatial and key-based operations.

2. initialization.sql

Creates shared database functions and global output tables required for the processing workflow. It also ensures that parallel workers can initialize these resources safely without conflicts.

3. filter_by_class.sql

Applies optional filtering rules to ways_tem based on configured klasse and objektart values. Rows that do not match the allowed filter conditions are removed from further processing.

4. building_address.sql

Matches buildings to nearby named ways based on their parsed street address and stores the result in buildings.address_street_id. If multiple matching ways exist, the nearest one is selected.

5. assign_buildings_to_ways.sql

Assigns each building to a suitable way and writes the result to buildings.assigned_way_id. Depending on the configuration, it prefers a more efficient direct match via the address information added in the last step or otherwise falls back to the nearest suitable way using postgis distance operators.

6. merge_candidates.sql

Creates temporary merge candidate data for ways_tem by analyzing neighbouring line endpoints within a distance tolerance. It identifies adjacent way segments and stores the required information for later way-merging steps.

7. merge_chain.sql

Builds connected chains of mergeable ways based on the previously identified merge candidates. It groups linked way segments into connected components so they can be merged in later processing steps.

8. merge_ways.sql

Merges connected way segments in ways_tem into single way geometries based on the previously generated chain candidates. It uses update_assigned_way_id_after_merge to update affected building-to-way assignments after the merge.

9. filter_isolated_loop_short.sql

Filters selected ways from ways_tem by removing loops, isolated ways, and short segments depending on the configured rules. After filtering, it uses update_assigned_way_id to update affected building-to-way assignments to be connected to the adjacent street of the filtered street and, where applicable, adds the filtered way’s length to the adjacent street that takes over its connections, so the total length from filtered ways can be tracked.

10. segment_intersecting_ways.sql

Splits intersecting ways in ways_tem at their intersection points and reinserts the resulting segments. This step ensures that crossings are represented as separate connected way segments for later network generation.

11. generate_building_to_way_connection.sql

Generates building-to-way connection lines and updates the related way attributes in ways_tem. It then creates ways_tem_connection as a copy of ways_tem and splits the affected ways at the building-to-way connection points only in ways_tem_connection.

12. assign_postcodes.sql

Assigns postcode values to the generated temporary way and connection tables based on postcode polygon intersections. This ensures that the processed geometries can be linked to postcode-based downstream analyses.

13. insert_temp_tables.sql

Inserts the final processed temporary way and connection data into the global output tables for the current AGS. Existing rows for the same AGS are replaced to keep the results idempotent.

14. insert_nodes.sql

Creates node tables by clustering way endpoints and inserting the resulting junction points together with their related way IDs. It generates nodes for both ways_per_junction and ways_per_connection.
